Why fibres wander
Woven fabric fitted to a dome behaves like a pin-jointed net (Mack & Taylor 1956): the yarns can't stretch but the weave shears, so the 0/90 grid stays square along the two starting fibres and closes up towards the diagonals; our net reaches 42° of shear near the rim before it runs out of room.
Predict · at 0:48 in the video
Do the fibres stay at zero and ninety everywhere?
No. Along the two starting fibres, they nearly do. But out along the diagonals the squares close up.
